1.2714 Tool Steel (DB6)

1.2714 Hot-Work Die Steel: Exceptional Toughness for Forging. Nickel-modified alloy for high-impact resistance in heavy-duty hot-work.

1.2714 Tool Steel (DB6)

1.2314 (L6/DB6) is a nickel-chromium-molybdenum-vanadium alloy steel known for its extreme toughness and resistance to thermal shock. It is the primary choice for heavy forging dies where the material must withstand repeated mechanical impact at elevated temperatures.

Chemical Composition	Percentage %
Carbon	0.55%
Vanadium	0.10%
Nickel	1.70%
Chromium	1.10%
Molybdenum	0.50%

The heat treatment process for 1.2714 tool steel must be carefully tailored to the specific characteristics of each component, including its size, shape, and section thickness. Key parameters such as heating temperature, controlled cooling rate, and soaking duration are selected based on the performance requirements of the material. Factors like furnace configuration, quenching media, and handling or transfer systems also significantly influence the final mechanical properties. To ensure optimal hardness, toughness, and dimensional stability, consultation with a qualified heat treatment expert is strongly recommended.

Certified Quality Assurance

At Progressive Metal Manufacturing, we maintain a rigorous quality management system to ensure that every batch of 2714 alloy steel meets the highest industrial standards. Our supply chain is fully compliant with ISO 9001 protocols, providing a foundation of traceability and consistency. For engineers and manufacturers, this means receiving a high-performance tool steel that is chemically verified and mechanically sound, allowing for predictable results in the most demanding forging environments.

Industrial Applications & Versatility

2714 (56NiCrMoV7) is a premium hot-work tool steel recognized for its exceptional toughness and resistance to thermal shock.

Its specialized alloy composition makes it the industry standard for high-stress metal-forming processes.

Key applications include:

Forging & Pressing: Essential for the production of heavy-duty forging dies, hot-pressing tools, and hammer blocks.

Precision Tooling: Ideally suited for mandrels, embossing tools, and high-strength punches.

Molding & Extrusion: Used extensively in the manufacture of robust molds and dies that must maintain structural integrity under intense heat and pressure.

Precision Supply & Custom Specifications

We provide a versatile range of 2714 steel formats, expertly processed to match your specific engineering blueprints.

Our facility utilizes advanced sawing technology to deliver materials ready for immediate production, reducing your internal lead times.

Our supply capabilities include:

Precision-Cut Round Bar: Sawn to your exact length specifications, whether you require a single prototype or high-volume cut pieces.

Custom Rectangular Sections: Precision-milled or sawn from flat bar and plate to your unique geometric requirements.

Ready-to-Tool Blocks: Available in various thicknesses to suit heavy-duty industrial applications.

Our technical sales team is standing by to assist with custom tolerances and logistical planning for your next project.
